Technical specifications:
General Specifications
- Rated Output Power: 50W RMS
- Power Supply: 100-240Vac, 50Hz/60Hz
Audio Specifications
- Transducers:
- Woofer: 1 x 120mm
- Tweeter: 3 x 20mm
- Frequency Response: 50Hz - 20kHz (-6dB)
- Signal-to-Noise Ratio: > 80dB
Dimensions
- Product Dimensions (W x H x D): 289.2 x 287.5 x 130 mm / 11.39" x 11.32" x 5.12"
- Packaging Dimensions (W x H x D): 312 x 322 x 172 mm / 12.28" x 12.67" x 6.77"
- Net Weight: 4.2kg / 9.25 lbs
- Gross Weight: 3.33kg / 7.34 lbs
Control and Connection Specifications
- Bluetooth Version: 5.3
- Bluetooth Profile: A2DP 1.4, AVRCP 1.6
- Bluetooth Transmitter Frequency Range: 2400MHz - 2483.5MHz
- Bluetooth Transmitter Power: ≤ 12 dBm (EIRP)
- Bluetooth Transmitter Modulation: GFSK, π/4 DQPSK, 8DPSK
- USB Port: Type C
- USB Rating: 5V / 2.1A (Max)
- Supporting File Format: mp3
Battery
- Battery Type: Li-ion 17.14 Wh (equivalent to 3.63 V/ 4722 mAh)
- Battery Charge Time: 4 hours
- Music Play Time: Up to 8 hours (dependent on volume level and audio content)
Cables
- Cable Type: AC Power Cable (type varies by regions)
- Cable Length: 2.0 m / 6.6 ft
- USB Charge Out: 5V / 2.1A (Max)
Items included:
- Harman Kardon Onyx Studio 9
- Power Cable
- Quick Start Guide
- Safety Sheet
- Warranty Card
